PC-850SD-D is a high-end double-positioning visual machine for rigid box and book cover production.
Automatic viusal double-positioning machine for rigid box and book cover PC-850SD-D, it is suitable for positioning box and cover, which avoid the manual positioning deviation especially for cover making. High positioning, dual function.
| Model | PC-850SD-D |
| Paper size | L:120mm-1000mm W:120mm-760mm |
| Paper thickness | 80-300gm² |
| Box double fixed maximum size | L350*W230*H80mm |
| Maximum box size | L500*W400*H120mm |
| Minimum box size | L60*W60*H15mm |
| Maximum shell size | L950*W500mm |
| Minimum shell size | L130*W70mm |
| Grey board fast counting | 1-4pcs |
| Thickness of gray board | 1-4mm |
| Production speed | 20-25pcs/min |
| Positioning accuracy | ±0.1mm |
| Motor power | 8KW/380V 3Phase |
| Gas source requirements | 10L/min 0.8MPa |
| Machine weight | 2000KG |
| Machine dimensions | L7600*W4300*H2150mm |
Our machines can be tailored to your specific workflow.
Tell us about your primary box dimensions, target output, and material types for a tailored proposal and ROI analysis.
